PowerVisa Power Quality Analysers

Lead Time MOQ
In Stock 1

See documents for individual model specification sheets

  • Description
  • Specifications
  • Documents
  • PowerVisa Power Quality Analysers are equipped with 8 independent channels, and is the only 3-phase advanced power monitor to have a built-in colour touch screen. Automated setups provide instant detection of circuits and configurations, ensuring that the instrument is ready to successfully collect data.

    Users can select the length and mode of data collection, including troubleshooting, data logging, power quality surveys, energy and load balancing. The PowerVisa mains monitor collects data at 256 samples/cycle/channel, offers RS-232, Ethernet or USB remote communications.

    Measurements 4 differential inputs, 1-600 Vrms, AC / DC, 0.1% rdg + 0.05% FS, 256 samples/cycle, 16 bit ADC, 4 inputs with CTs 1-6000 Arms, CT -dependent, AC/ DC, 256 samples/cycle, 0.1% rdg + CTs, 16 bit ADC, Frequency range, 10 mHz resolution, 45-65 Hz and Phase lock loop – standard PQ mode
    Dimensions (WxDxH) 203x64x300mm
    Nett Weight 1.8Kg
    Delivery Time Ex stock
    Warranty 12months

Other ranges and products

Unit price POA
